8860
8860标准ATX
8860标准ATX
高扩展性
高通风面板设计
可选CE/EMI处理工艺
可选0.6mm厚度
Form Factor (Midi, Micro, Mini ITX, Full)Midi ATX
Chassis0.5mm  SGCC outside black painting
PSU Form FactorTOP/ATX
M/B Form FactorATXM-ATXITX
Front PanelABS,Mesh
Top Panelmetal cover
Side PanelLeftmetal cover

Rightmetal cover
External Drive Bay(s)5.25" (ODD)*3 or 2

3.5"*0  or *1 (exchange with 5.25")
Internal Drive Bay(s)3.5" (HDD)*4

2.5" (SSD)*1
Tool-less ODD HDDOptional
I/OButtons*2

USB2.0 Port(s)*2

HD Audio Support*1

Type C(2.0)*0

Card reader*1 (optional)
Cooling Fan  SupportFront1x80/92/120mm (Fan optional)

Top0

Rear1x80/92/120mm (Fan optional)

Left Side2x120mm  (Fan optional)
Slots
*7
DimensionsChassis(L)410*(W)185*(H)412mm

Full Case (inc Fascia)(L)464*(W)185*(H)420mm

Net Weight (Kg)5.2kgs

Gross Weight (Kg)6.2kgs
VGA Card Length
1.Up to 340mm(without HDD bracket)
VGA Card Length
2.Up to 270mm(with HDD bracket)
CPU Cooler Height
158mm
Cable Management Depth
15mm
